Access Point – Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC

Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Access Point - Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
2.400.000
  • Thương hiệu: PLANET
  • Tình trạng: Mới 100%
  • Model: WBS-512AC
  • Cổng:
    – 1 10/100/1000BASE-T RJ45 POE
    – 1 10/100/1000BASE-T RJ45
  • Tốc độ: 900Mbps
  • Bảo hành: 24 tháng

Giới thiệu sản phẩm

Access Point – Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC

Flexible and Reliable Outdoor Wireless Solution with Superior Performance

PLANET WBS-512AC 802.11ac WAVE 2 900Mbps Outdoor Wireless CPE offers a better range and excellent throughput than those of the traditional wireless device. With the standard IEEE 802.3at Power over Ethernet (PoE) design, the WBS-512AC can be easily installed in the areas where power outlets are not available. The WBS-512AC is definitely suitable for wireless IP surveillance, and bridge link of building to building and backbone of public service. Additionally, the self-healing capability keeps connection alive all the time. With the IP55-rated outdoor enclosure, the WBS-512AC can perform normally under rigorous weather conditions, meaning it can be installed in any harsh, outdoor environments.



Benefits of MU-MIMO under 802.11ac Wave 2

With the MU-MIMO Wave 2 technology, the WBS-512AC, installed in public areas such as hotspots, airports and conferences, reduces the frustration that Wi-Fi users often experience in downloading web pages, e-mail file attachments and media contents. For cellular operators, the WBS-512AC provides a better Wi-Fi user experience, reducing the likelihood of users turning off Wi-Fi and putting more load on the cellular network. For enterprises, this technology also can solve Wi-Fi congestion issues in open work spaces and conference rooms.



Designed for Various Requirements

The WBS-512AC is specially designed for long-distance outdoor surveillance and wireless backhaul solutions that are capable of establishing stable bridge connection through the embedded 14dBi unidirectional antenna. To provide maximum performance, the WBS-512AC can implement up to 6 operation modes and is easy to use where a multitude of applications in communities, warehouses, campuses, harbors, etc. can be made.



3 Simple Steps to Set Up PtP Connection

Without needing to enter the Web interface for configuration, the WBS-512AC has the DIP switch for setting to master (AP mode) and to slave (repeater mode). User only needs three simple steps to establish the PtP connection without any difficulty. By just switching the button to “Master” on the master AP, and pressing the reset button, the PtP connection can be established in 2 minutes as the connection steps are shown below.



Multiple SSIDs with VLAN Tagging

The WBS-512AC supports WPA/WPA2, and the 802.1X RADIUS authentication to secure the wireless connection. Besides, the supported IEEE 802.1Q VLAN allows multiple VLAN tags to be mapped to multiple SSIDs to distinguish the wireless access. This makes it possible for the WBS-512ACN to work with managed Ethernet switches to have VLANs assigned to a different access level and authority.



Flexible and Reliable Outdoor Characteristics

The WBS-512AC is definitely suitable for wireless IP surveillance, and bridge link of building to building and backbone of public service. Additionally, the self-healing capability keeps connection alive all the time. With the IP55-rated outdoor enclosure, the WBS-512AC can perform normally under rigorous weather conditions, meaning it can be installed in any harsh, outdoor environments. With the flexible DC input or Power over Ethernet (PoE) option, the WBS-512AC can be easily installed depending on the environmental condition.



Optimized Efficiency in AP Management

The brand-new GUI configuration wizard helps the system administrator easily set up the WBS-512AC step by step. Besides, the built-in Wi-Fi analyzer provides real-time channel utilization to prevent channel overlapping to assure greater performance. With the automatic transmission power mechanism, distance control and scheduling reboot setting, the WBS-512AC is easy for the administrator to deploy and manage without on-site maintenance. Moreover, you can use PLANET NMS-500 or NMS-1000V AP control function to deliver wireless profiles to multiple APs simultaneously, thus making the central management simple.

Xem thêm

Đánh giá Access Point – Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC

5 0% | 0 đánh giá
4 0% | 0 đánh giá
3 0% | 0 đánh giá
2 0% | 0 đánh giá
1 0% | 0 đánh giá
Đánh giá Access Point – Bộ phát Wi-Fi Ngoài Trời CPE AC900 PLANET WBS-512AC
Gửi ảnh chụp thực tế
0 ký tự (tối thiểu 10)
    +

    Lưu ý: Để đánh giá được duyệt, quý khách vui lòng tham khảo Hỗ trợ

    Chưa có đánh giá nào.

    Chưa có bình luận nào

    Thông số kỹ thuật

    Hardware WBS-512AC
    Standard Support IEEE 802.11a/n/ac
    IEEE 802.11i
    IEEE 802.3 10BASE-T
    IEEE 802.3u 100BASE-TX
    IEEE 802.3x flow control
    IEEE 802.11k, 802.11v, and 802.11r
    Dimensions (W x D x H) 87 x 38 x 260 mm
    Weight 405g
    Power Requirements 48V DC IN,0.5A, IEEE 802.3 at PoE+ or
    12V DC IN, 1.0A from DC Jack
    Power Consumption (max.) < 10W
    Interface Wireless IEEE 802.11a/n/ac, 2T2R
    PoE: 1 x 10/100/1000BASE-TX, auto-MDI/MDIX, 802.3 at PoE In
    LAN: 1x 10/100/1000BASE-TX, auto-MDI/MDIX
    Button Reset/Pair button, PtP Switch
    Antenna Built-in 14dBi directional antenna with dual polarization
    Half-power beam width
    Horizontal: 50 degrees
    Vertical: 15 degrees
    Data Rate IEEE 802.11a: up to 54Mbps
    IEEE 802.11n (20MHz): up to 150Mbps
    IEEE 802.11n (40MHz): up to 300Mbps
    IEEE 802.11ac (80MHz): up to 867Mbps
    Media Access Control CSMA/CA
    Modulation 802.11 a/n/ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
    Frequency Band FCC: 5.180~5.240GHz, 5.745~5.825GHz
    ETSI: 5.180~5.700GHz
    Operating Channels FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 channels)
    ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 channels)
    5GHz channel list will vary in different countries according to their regulations.
    Max. Transmit Power (dBm) FCC: up to 25 ± 1dBm
    ETSI: < 20dBm (EIRP)
    Receiver Sensitivity (dBm) Network Mode Data Rate Receive Sensitivity (dBm)
    802.11a 6Mbps -92
    54Mbps -75
    802.11n HT20 MCS0/MCS8 -91
    MCS7/MCS15 -72
    802.11n HT40 MCS0/MCS8 -88
    MCS7/MCS15 -70
    802.11ac VHT20 MCS0 -92
    MCS8 -70
    802.11ac VHT40 MCS0 -89
    MCS9 -65
    802.11ac VHT80 MCS0 -87
    MCS9 -61
    Environment & Certification
    Operating Temperature -20 ~ 70 degrees C
    Operating Humidity 5 ~ 90% (non-condensing)
    IP Level IP55
    ESD Protection ± 8kV air-gap discharge
    ± 4kV contact discharge
    Surge Protection ± 4kV
    Regulatory CE, RoHS
    Software
    LAN Static IP/DHCP
    Supports IP-MAC binding
    WAN Type (GW/WISP mode) Static IP
    Dynamic IP
    PPPoE
    Wireless Modes Access Point
    Gateway
    Repeater
    Super WDS
    WISP
    Channel Width 20MHz, 40MHz, 80MHz
    Encryption Type 64-/128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 802.1X
    Wireless Security Enable/Disable SSID Broadcast
    Wireless Max. 32 MAC address filtering
    User Isolation
    Max. SSIDs 4
    Max. Wireless Clients 64 per radio (50 is suggested, depending on usage)
    Max. WDS Peers 4 (Up to 3 peers by using “One-click WDS”)
    Wireless QoS Supports Wi-Fi Multimedia (WMM)
    Wireless Advanced Auto Channel Selection
    5-level Transmit Power Control (Max. (100%), Efficient (75%), Enhanced (50%), Standard (25%), Min. (12.5%))
    Client Limit Control, Coverage Threshold
    Wi-Fi channel analysis chart
    Fast Roaming(IEEE 802.11k, 802.11r, 802.11v)
    Status Monitoring Device status, wireless client List
    PLANET Smart Discovery
    DHCP client table
    System Log supports remote syslog server
    VLAN IEEE 802.1Q VLAN (VID: 3~4094)
    SSID-to-VLAN mapping up to 4 SSIDs
    Self-healing Supports auto reboot settings per day/hour
    Management Remote management through PLANET DDNS/Easy DDNS
    Configuration backup and restore
    Supports UPnP
    Supports IGMP Proxy
    Supports PPTP/L2TP/IPSec VPN Pass-through
    SNMP v1/v2c/v3 support, MIB I/II, Private MIB
    Central Management Applicable controllers: WAPC-500, WAPC-1000, NMS-500, NMS-1000V
